Selection of the internal cabling
Once it was established that Bill was open to the revision and article, I contacted the owners of one of the most beautiful sounding cable brands I have encountered, Chris and Melissa Owen of Clarity Cable. Time and again the unpretentious looking Clarity Cable has lined up against very heavy hitters. Clarity Cable was the brand which convinced me that I did not need passive networks to achieve ultimate sound systems. It was tried against all comers in my room, and I am still largely using Clarity Cables to build audio systems. To date, the only cable to best it in every respect is the recently reviewed Silent Source The Music Reference line, which costs multiples more than Clarity Cables. Very few people can justify an approximately $25-20K expense for wiring a rig with Silent Source. For those who can afford it, I strongly recommend that cable. A far larger number of fans can swing $4-6K for a cable loom, which is one reason I use Clarity Cables as a reference for serious system builders. Thankfully, Chris Owen of Clarity Cable didn’t need much convincing of the validity of the project. He and his wife Melissa have judged numerous car audio competitions nationally and know importance of good cabling. Chris shared my enthusiasm that the wire upgrade would be efficacious. In fact, he was so intense about the project that he had discussions with Bill about how the terminations would be done. Chris had found a particular silver solder to sound the best and he did not want an alternative connection to alter the sound of his wires.
As Chris and Bill collaborated on the build out they resolved potential issues, as can be seen by Bill’s discussion of internal connections with a large diameter conductor and fine connection points on some drivers:
“The effect of increasing wire diameter was beneficial in providing a more ideal conduit for current flow. Damping improved in the bass section and the mids benefitted from more back to front depth in the stereo effort. The part that had concerned me regarding the transition to the ribbons was handily overcome by the fine job Melissa did terminating the wires to accommodate our tweeter lugs. The high pass filter Q changed a bit allowing me to go to slightly small high pass capacitors on the ribbon circuit (again due to improved damping).”
Notice that Bill is discussing damping, a measurable parameter of speaker performance. The effect of changing the wiring altered the sound as well as the high pass filter Q. I consider this a prime piece of evidence supporting the argument that cabling makes a measureable and audible difference in systems.
My confidence in the quality of Clarity Cables was reinforced further as Bill looked into them literally. He took apart as well as measured a sample and discovered a very high grade conductor:
“I find that easily 25% of the high end cables offered are inferior to simple highly stranded OFC cables. Some create rather bizarre ultrasonic behavior due to capacitive reactance, others may have a rolled off inductive top end. There is an abundance of pseudo-science tolerated in this sector of the industry. It is also why customers with exotics amps can experience overheating from frequencies that are out of the range of audibility. The Clarity cables are separately insulated strands of very high quality copper. This construction type minimizes both skin and proximity effect. It is solid science. The isolated conductors require more effort to terminate and the cost to manufacture is significantly higher. But Chris Owens puts the cost in the conductor, not in a glitzy poly filled jacket.”
One can see in Bill’s discussion that he respects the nature of the materials and measured performance of Clarity Cables. I had made the selection based on use, and Bill confirmed it by technical examination. I appreciate the fervency and thoughtfulness of these manufacturers as it convinced me the project would be carried out with the utmost attention to ultimate performance.
More than I bargained for
The scope of the rework expanded unexpectedly such that during the time the speakers were in Bill’s possession two additional improvements manifested themselves: a capacitor upgrade and a new Legacy AMT (Air Motion Tweeter) driver set. Bill had been quietly working on some new models, the most recent being the Aeris. The challenge of upgrading the wiring of the Whisper led to new discoveries which impacted the development of the Aeris.
Over the past several years Legacy has been adding speakers to what Bill has termed the Masters Series, tweaked designs worthy of being called Legacy’s ultimate products. One of these is the Focus SE and another is the Aeris, but the one quietly being developed which in turn impacted the Aeris was the Clarity Whisper. Here is an excerpt from my interview with Bill, in which I asked him about the impact of the rewiring:
D.S: Is it fair to say that you were convinced by this experiment that the internal wiring of a speaker system is critical to its optimum performance? What take away insights did you gain from this project in terms of the cabling and Legacy speakers?
B.D. I think the Aeris speaker was greatly influenced by this project, particularly in that it is the first product that we put on visible display the crossover components and internal wiring within the design.
Did you catch Bill’s pride in the materials and workmanship of the wiring and crossover? Legacy audio was so impressed by the wiring and crossover rework that they decided to show the world the circuit responsible for the improved sound!
